HI-7609829-3 SPARE EC SENSOR FOR HI-7609829/HI-7629829 SERIES OF PROBES
HI-7609829-3
The HI-7609829-3 is a 4-ring electrode conductivity sensor for use with Hanna’s HI-9829 Multi-parameter Portable Meter. The sensor body is made from durable ABS material and contains AISI 316 stainless steel electrodes.
Conductivity Sensor for the HI-9829
The HI-7609829-3 is a conductivity sensor with o-ring, to be used with the HI-9829 and HI-98290 series of multi-parameter meters.
Each module is colour-coded for easy installation and integration with the probe.
The HI-7609829-3 4-electrode conductivity sensor using the polarographic measurement principle ensures stable conductivity readings. Electrolytic conductivity measures the ability of water to conduct an electrical current. It is highly dependent on the amount of dissolved solids (such as salt) in the water. Absolute conductivity, temperature-corrected conductivity, salinity, seawater and water hardness (TDS) determinations are possible with measurements from this sensor.
IP68 - Dust-tight and protected against the effects of continuous immersion in water beyond 1m.
Läs mer
| Sensor | HI-7609829-3 | |
| Description | EC Sensor | |
| Measurement Type | EC , TDS, Salinity | |
| Measurement Range | 0.0 to 200.0 mS/cm; 0.0 to 400 mS/cm (absolute) | |
| Temperature Range | -5 to 55 °C | |
| Body | ABS/epoxy | |
| Colour code | Blue | |
| Dimensions | 111 x 17 mm | |
| Depth | 20 metres (65 feet) |
